Ficha Técnica del Producto

---

MODELO N°			TAC-24HSA/inverter
Type			heating pump
Control type			remote
Rated cooling capacity		Btu/h	24000(6800~25600)
		W	7030(1990~7500)
Rated heating capacity		Btu/h	24500(7200~29000)
		W	7180(2110~8500)
EER for cooling		Btu/h.w; W/W	10.95; 3.21
COP for heating		W/W	3,21
Moisture removal		Liters/h	2,5
Indoor noise level at cooling	High	dB(A)	47
	Med.	dB(A)	45
	Low	dB(A)	42
Outdoor noise level		dB(A)	62
ELECTRICAL DATA
Power supply
Voltage Range		V	155~265
Rated current	Cooling	A	10.0(2.8~10.6)
	Heating	A	10.2(3.0~12.1)
Rated input	Cooling	W	2190(620~2340)
	Heating	W	2240(660~2650)
Annual energy consumption		kwh (cooling)	1095
Max current		A	10.6/12.1
Max input		W	2340/2650
Refrigerating System
Refrigerant/Charge		Gram	R410A／2400g
Compressor	Type		Rotary
	Model		DA150S1C-20FZ
	MFG		Toshiba
Evaporator			3-bend
Condenser			double-arranged
FAN SYSTEM
Indoor air circulation Cooling/heating		m3/h	1000/1100
Indoor fan type			Cross Flow
Indoor fan speed H/M/L	Cooling	rpm	1300/1200/1050
	Heating	rpm	1300/1200/1050
	Dry	rpm	1050
	Sleep	rpm	1050
Indoor fan motor output		W	50
Outdoor fan type			Propeller fan
Outdoor fan speed		rpm	860/720
Outdoor fan motor output		W	60
CONNECTIONS
Refrigerant coupling
Connecting Pipe	Gas	Inches	5/8''
	Liquid	Inches	3/8''
Connecting Wiring	Size x Core number		4x0.75
OTHERS
Suitable area		m2	30-50
Net dimensions	Indoor	mm	1033x313x202
(W x H x D)	Outdoor	mm	900×805×360
Net weight	Indoor	kg	14
	Outdoor	kg	61
Packing dimensions	Indoor	mm	1103x400x300
(W x H x D)	Outdoor	mm	1031×925×447
Gross weight	Indoor	kg	17
	Outdoor	kg	66
